TECHNICAL SPECIFICATION OF P10 OUTDOOR DISPLAY

TECHNICAL SPECIFICATION OF P2.9 DISPLAY

  • Pixel Configuration :SMD
  • Pitch (mm) :2.91
  • Pixel Density :65536
  • LED Arrangement :SMD1921
  • Module Resolution :128x64
  • Module Thickness :21.5mm
  • Grey Scale (bit） :≥14bit
  • Brightness Level :5000 nits
  • Cabinet Size(mm) :500*1000 or 500*500
  • Cabinet Weight(Kg) :14KG
  • Cabinet Thickness(mm) :80mm
  • Max Power Consumption/㎡ :760w/㎡
  • Ave Power Consumption㎡ :300w/㎡
  • Visual View Angle :160°/90°
  • Operating Temperature :-10±60°
  • Refresh Rate :≥3840Hz
  • Protecting Rating :IP65
  • Viewing Angle (H/V) :140/120°
  • AC Operating Voltage :200~240V
  • Module Maintenance :Front/Rear
  • Panel Installation Type :Hanging, Stacking
  • LED Lifetime :1,00,000 Hrs
  • Storage Temperature :-40~60 ℃
  • Operating Temperature :-10~40 ℃
  • Storage Humidity (RH) :10%~90%
  • Operating Humidity (RH) :10%~85%
  • Pixel Per Panel :128x256
